Sigma MP is a multiplace hyperbaric system which accommodates 6-8 patients simultaneously, including critical care patients.
• Reduces staffing requirements per patient while increasing patients that can be treated
• Available in standard 6, 8, 12, 18 patient or custom configurations for flexibility
• Entry lock permits a physician to enter or leave the system during treatment
• Built in breathing system provides optimal oxygen consumption per patient.
• A minimum of 100 cubic feet of space for each seated patient
• Ergonomically designed patient seating for comfort
• Pressurized with air for increased safety
| Attendant accommodation | ● |
| Built-in patient breathing system | ● |
| Dualplace | |
| Fire suppression system | ● |
| Locking gurney for transport | ● |
| Monoplace | |
| Multiplace | ● |
| Non-invasive blood pressure penetration | ● |
| Smooth bore penetrations | ● |
| Ventilator feed-through | ● |
Equipment manufactured by Perry Baromedical Corp. will be free from defects in materials and workmanship under normal use for a period of 12 months from the date of delivery. Extended warranty and service programs are also available.
For Standard Sigma MP-12:
Maximum Operating Pressure: 73.5 psig/6 ATA(6 bar)
Internal Diameter: 96"
Overall length: 32'
Main Compartment Length: 24'
Entry Lock Length: 6.5'
Weight: 32,000lb
Rectangular Entry Door: 32"x66"
Circular Entry Door (2): 36" ID
View Ports:
End Heads (CCTV Camera Ports): 4" ID
Entry Lock (2): 10" ID
Main Compartment (6): 10" ID
Medical Lock:
One 12" ID x 18" long bolt-on medical lock in the treatment compartment.
Perry Baromedical designs, manufactures, installs and services a full line of hyperbaric oxygen therapy systems, including monoplace, dualplace and multiplace systems.
